MD27 Flat Pack Capsule One Bedroom 27m2

Nine square metres more floor, and that extra length buys a walled bedroom separate from the living area rather than a sleeping zone within one room. Shell, glazing, bathroom specification, smart controls, delivery format and warranty are all the same. Air conditioning steps up to a 2 HP reverse cycle split to suit the larger volume.

That is the point of the flat pack format. The panels and modules are carried in and bolted together in place, so you do not need crane access or a clear run wide enough for a whole building. Send photos of the access path and any gates, steps or level changes and we will confirm before you order.

In almost every Australian council area, yes. A one bedroom secondary dwelling needs a development application or complying development certificate. It is built to order to NCC Class 1a requirements, with compliance documentation supplied, but approval is the buyer's responsibility and depends on your zone, site area and setbacks. We cannot promise it.

A reinforced concrete slab or screw piles, engineered locally to your soil classification (the site test that grades how much your ground swells and shrinks with moisture) and wind classification. Screw piles are often chosen on the constrained sites this model is designed for, since they need far less access than a concrete pour. Your builder sets the footing out to the drawings issued with the order.

The unit arrives pre wired and pre plumbed to connection points. A licensed electrician connects it to your switchboard and a licensed plumber connects water supply and drainage, including any required trade waste or sewer junction work. Those connections are completed on site by your trades and are not included in the supply price.

An entrance staircase and platform, a full kitchen system, a bed and wardrobe, a smart toilet, indoor shading curtains, a projector or smart television package, double layer wall insulation, electric underfloor heating, triple glazing and anti corrosion treatment for coastal sites. Adding these in the factory is neater and cheaper than retrofitting on site.

Production typically runs for around 20-30 working days and ocean freight to an Australian port typically takes around 20-30 transit days, including customs clearance, quarantine inspection and final road delivery. Assembly on a prepared footing takes days. Firm dates are confirmed in writing with your order rather than estimated over the phone.

Warranty duration, covered components, exclusions and remedies are confirmed in your quote and order documents, with claims handled through Future Modular Homes. Cover assumes assembly to the supplied setup pack on the specified footing and connection by licensed Australian trades, so keep the assembly and commissioning records with the compliance documentation.
